HDMI 2×2 Video Wall (4K30Hz)

Product Overview

Introduction:

The EiRA ER2635VW 4K 2×2 Video Wall Controller supports HDMI or DVI input and provides four HDMI outputs. Its primary function is to split a single high-definition HDMI or DVI image into four separate sections and distribute them across four display units such as LCD TVs or rear-projection screens. When connected together, these four displays create a seamless, large-format dynamic video wall. The controller also supports input resolutions up to 1920×1080 and enables vertical screen splicing mode for flexible display configurations.

Features:

•  Supports both HDMI and DVI input with HDCP 1.4/1.3 compliance.
•  Enables vertical screen splicing in 1×1, 2×1, 3×1, and 4×1 configurations, and supports 90° and 270° image rotation. (Input limited to 1920×1080/8-bit for these modes.)
• Allows 180° rotation of any output image, making it suitable for inverted display installations.
•  Features power-off memory, automatically restoring previous settings when restarted.
•  Provides four HDMI output ports for multi-display setup.
•  Supports RGB 4:4:4 output for high-quality colour reproduction.
•  Equipped with RS232 control for professional system integration.
•  Offers multiple splicing layouts including 1×1, 1×2, 2×1, 1×3, 3×1, 2×2, 1×4, and 4×1, ensuring flexible and easy plug-and-play operation.
•  Supports input resolutions of up to 3840×2160@30Hz, 1920×1080@60Hz, and 1280×720@60Hz.
•  Supports output resolutions of 1280×720@60Hz, 1920×1080@60Hz, and 3840×2160@30Hz.
• Incorporates border masking technology that adjusts blanking width at panel edges, minimizing bezel interference and ensuring a smoother, more seamless video wall display.
